The DSP Compact Cyclone Sand Plant range is used to wash sand, recover maximum fines, and dewater sand in a modular self-contained unit.
The DSP Compact Plant maximises the yield of saleable sand and produces higher quality sand. The DSP range is simple to operate and has been proven to be both energy and cost efficient for sand production.
Model |
Pump |
Dewatering |
Cyclone |
Max |
---|---|---|---|---|
DSP50 | 22kW | 2500 x 1200 | 380mm | 40 TPH |
DSP90 | 30kW | 2500 x 1200 | 500mm | 75 TPH |
DSP120 | 37kW | 2500 x 1200 | 500mm | 90 TPH |
DSP150 | 45kW | 3660 x 1545 | 660mm | 130 TPH |
DSP250 | 75kW | 4100 x 1800 | 800mm | 220 TPH |
